Premium Digital Instrument Cluster for Ford FG Falcon

SKU: CP-2951

$1895.00

Select your Options

Product Description

FORD FG Falcon MK1 & MK2 Premium Digital Instrument Cluster

This Digital Instrument Cluster will convert your Ford FG Falcon into a modern OEM digital dashboard experience, while retaining key vehicle data and factory-fit integration.

This digital cluster — a very large 12.3 inch high-resolution IPS display — offers sharp graphics, seamless animations, and remarkable visibility in any driving environment.

Choose Classic, Sport or Off-Road display modes, depending on your driving style — factory-like or performance-oriented?

The cluster comes loaded with Wireless Apple CarPlay, so you can connect without cables to navigation, music, calls and apps.

With Bluetooth 5.3 and dual Bluetooth connectivity, two devices are connected at once.

The built-in speaker is great for hands-free calling and music, while call audio can be routed through your car’s speakers via the cluster, which will also hook up to your current head unit via Bluetooth.

You can see in real time the vehicle information (speed, RPM, fuel consumption, oil temperature, coolant temperature, oil pressure, and vehicle status).

Tyre details are available from optional Bluetooth TPMS sensors (sensors sold separately).

Very simple to install.

The cluster is designed for the Ford FG Falcon and will plug right into the factory location, and can be returned to the previous setup as needed.



Key Highlights

  • 12.3″ High Resolution IPS display (1920 × 720)

  • Wireless Apple CarPlay & Wireless Android Auto

  • Bluetooth 5.3 with support for two devices

  • Built-in speaker for calls & alerts

  • Audio output from the car's speakers (Bluetooth connection to the head unit)

  • Real-time vehicle data & OEM-style graphics

  • Classic, Sport & Off-Road display modes

  • Ford FG Falcon Plug & Play installation

Important Information

Note: Once placed, all orders are final and non-refundable because the items in the order are specially allocated and reserved.

Premium 12.3″ Digital Instrument Cluster – Ford FG Falcon

CPU & System

  • Processor: T507 Quad-Core (1.5GHz)

  • Operating System: Linux 4.9.170

  • RAM: 1GB

  • Internal Storage: 4GB


Connectivity & Smart Features

  • Wireless Apple CarPlay

  • Bluetooth 5.3

  • Dual Bluetooth Connection (connect two devices simultaneously)

  • Built-in Speaker for calls and alerts

  • Hands-Free Calling Support

  • Music Playback Support

  • Audio Output via Vehicle Speakers

    • Cluster connects to the car head unit via Bluetooth for audio playback



Display

  • Screen Size: 12.3 Inch

  • Panel Type: IPS Display

  • Resolution: 1920 × 720

  • High Brightness & Wide Viewing Angles



Functions & Vehicle Data

  • Original tyre information (optional Bluetooth tyre pressure sensors required; sensors sold separately)

  • Oil temperature

  • Water (coolant) temperature

  • Oil pressure

  • Fuel consumption

  • Vehicle body balance display

  • Speed, RPM, gear position

  • Real-time driving and vehicle status information



Driving Modes (UI Themes)

  • Classic Mode

  • Sport Mode

  • Off-Road Mode



Electrical Specifications

  • Operating Voltage: 9V – 16V

  • Operating Current: 0.8A – 1.5A

  • Standby Current: < 3mA



Installation

  • Plug & Play Installation

  • Designed specifically for Ford FG Falcon

  • No wire cutting or wiring modifications required

Compatible Vehicles

This product supports the following vehicle models

FG MK1

Frequently Asked Questions

This digital instrument cluster is designed for Ford FG Falcon MK1 and MK2 models, including selected XR6, XR6 Turbo, XR8, G6E, F6, and GT variants.
